• Manifold for high safety standards
• SIL 4 certified interlock solution
• Integral construction
• Several DBB lines with a single control element
• Suitable for HIPPS systems - High Integrity Pressure Protection System

Applications

• Interception of pressure instruments for HIPPS systems and instrumental safety systems

Connections

• Threaded (ASME B1.20.1)
• Flanged (ASME B16.5)

Rating

• Max #10000 (690 bar)

Seals

• Standard: PTFE
• Optional: Graphite

Peculiarities

• Reduction of the construction costs of a high pressure system
• Line protection from overpressures
• Reduction of polluting emissions into the atmosphere due to high pressure lines

Certifications

• SIL 4 - IEC 61508
• PED 2014/68/EU
• ATEX 2014/34/EU
• IP66 (with box)
• CRN for Canada
• CU-TR for EAC Countries
